A Digipeater is a station that does digital repeating. Unlike full-duplex VHF/UHF voice repeaters, a digipeater will receive a packet, process it, and retransmit on the same frequency. A digipeater which operates on multiple frequencies or routes between RF and Internet traffic is called a gateway.
In classic packet radio each such hop had to be explicitly included in the packet by the sender at origination. In APRS all digipeaters use generic aliases. The sender does not have to know the callsign of the digipeater but just indicate the number of hops he wants to go.
Digipeating is defined in AX.25 specification document. An initiating station can include in each packet a list of intermediate stations which are supposed to digipeat the packet, passing it on toward the desired destination. The list of intermediate stations is called the path. Stations receiving packets examine the path of received packets. Using it’s configuration information a receiving station can decide if a packet is a candidate for digipeating. When this is true the packet addressing information is modified slightly and the modified packet is transmitted.
The idea is to get packets to propagate outward from the initiating station… but not so far as to be an unnecessary burden on the system and surrounding users.
Winlink – RMS Gateway (Radio Mail System)
The RMS Gateway Digipeater that LMARC owns and operates covers the Chattanooga, TN and Lookout Mountain areas, as well as most all of NW GA. It operates on a frequency of 145.750 and is designated W4EDP-10.
Winlink, also known as the Winlink 2000 Network, is a worldwide radio messaging system that uses amateur-band radio frequencies to provide radio interconnection services that include email with attachments, position reporting, weather bulletins, emergency relief communications, and message relay. The system is built and administered by volunteers and administered by the Amateur Radio Safety Foundation Inc.
Generally, email communications over amateur radio in the 21st century is now considered normal and commonplace. Email via High frequency (HF) can be used nearly everywhere on the planet, and is made possible by connecting an HF single sideband (SSB) transceiver system to a computer, modem interface, and appropriate software. The HF modem technologies include PACTOR, Winmor, and Automatic Link Establishment (ALE).
The Winlink system is open to properly licensed amateur radio operators. The system primarily serves radio users without normal access to the internet, government and non-government public service organizations, medical and humanitarian non-profits, and emergency communications organizations. Duly authorized MARS operators may utilize the MARS part of the system. As of July 2008, there were approximately 12,000 radio users and approximately 100,000 internet correspondents. Monthly traffic volume averages over 100,000 messages.
July 21, 2019
The following was received this from the Winlink team overnight, please read and follow guidelines:
If you are a US-licensed station that routinely connects to a foreign gateway, or a non-US-licensed station that connects with a US gateway, you may be affected by new CMS behavior. The Winlink CMS now will enforce US Third-Party Message rules.
Because Winlink is being severely criticized for allowing US client and gateway operators to violate US amateur radio third-party traffic rules, we are today starting to test automatic enforcement of these rules. Part 97.3(47), 97.115 and 97.117 apply.
If you attempt to send or receive a third-party message between a US-licensed station and another station the US does not have a third-party communication agreement with, you may receive a service message saying the message will violate the applicable rules and that the message is refused (if you’re sending) or being held at the CMS (if you are receiving). Alternative means to successfully send or receive the message will be explained. The US has treaties with most countries in the North and South America, but not most European, Asian and Pacific countries.
If you are a US-licensee, you should have no trouble sending and receiving to/from internet addresses if you connect with another US-licensed gateway, or one licensed in Central or South America — as long as the US has a third-party agreement with the licensing country.
If you are a non-US licensee, you should have no trouble sending and receiving to/from internet addresses if you connect to non-US licensed gateways.
We wish this was not necessary, but we have relied on US client and gateway operators to know the rules and obey them—and most have ignored them, unfortunately for all of us. In order to clean up the violations we are taking these measures to keep US Winlink operators legal. All licensees have an obligation to study, know, and obey the Amateur Radio Rules.
New monitoring and enforcement measures are coming into play with the establishment of a new Volunteer Monitor Program, now being set up by the ARRL at the request of the US FCC. We’re doing this to make it easier for US operators to avoid loosing their licenses!
We will be tweaking the behavior of this new mechanism to make it as friendly and informative as it can be. Please bear with us as we make changes.
Thanks and 73,
Winlink Development Team
APRS (Automatic Position Reporting System)
The APRS Digipeater that LMARC owns and operates covers the Chattanooga, TN and Lookout Mountain areas, as well as most all of NW GA and NE AL. It operates on a frequency of 144.390 and is designated N4LMC-3.
Automatic Packet Reporting System (APRS) is an amateur radio-based system for real time digital communications of information of immediate value in the local area. Data can include object Global Positioning System (GPS) coordinates, weather station telemetry, text messages, announcements, queries, and other telemetry. APRS data can be displayed on a map, which can show stations, objects, tracks of moving objects, weather stations, search and rescue data, and direction finding data.
APRS data is typically transmitted on a single shared frequency to be repeated locally by area relay stations (digipeaters) for widespread local consumption. In addition, all such data is typically ingested into the APRS Internet System (APRS-IS) via an Internet-connected receiver (IGate) and distributed globally for ubiquitous and immediate access (see more below on this). Data shared via radio or Internet is collected by all users and can be combined with external map data to build a shared live view. Take a look at https://aprs.fi and see what’s happening around you!
APRS has been developed since the late 1980s by Bob Bruninga, WB4APR, currently a senior research engineer at the United States Naval Academy. He still maintains the main APRS Web site. The initialism “APRS” was derived from his call sign.
An IGate is a type of gateway APRS station. It is similar to a network router in the TCP/IP world, or to a “voting receiver” in a wide-area radio repeater network. The IGate’s job is to selectively allow packets to cross between the APRS-IS and the local RF network.
RF –> APRS-IS
Going from RF to APRS-IS is the simpler of the two operations. The IGate station needs to successfully connect to APRS-IS which requires a rudimentary password. Packets received via RF are sent out on the APRS-IS side. IGate implementations take care of reformatting the packet for the APRS-IS.
APRS-IS –> RF
Gating to the RF side is a little trickier. The technical parts are not difficult but the limitations of the RF channel and regulatory restrictions attendant with radio transmissions make things more difficult. Many IGate implementations will only send to RF those packets destined for stations that have been recently heard on the RF side or that are in a list of designated destination stations.
“Digipeater” is short for “Digital Repeater”; a repeater for packet data rather than voice. Unlike the standard voice repeater that receives on one frequency and retransmits what it hears simultaneously on another frequency, the usual digipeater is a single frequency device. It receives a packet of data, stores it in internal memory and then a moment later retransmits it on the SAME frequency. Digpeating is much more critical to APRS than to conventional packet because APRS heavily involves packet data transmission to and from moving vehicles. Traditional packet was overwhelmingly used between fixed locations, typically with better and higher antennas.
LMARC Owned and Operated Digipeaters
- Winlink RMS Gateway – 145.750, W4EDP-10. Greater Chattanooga, Lookout Mountain, TN, NW GA and NE AL areas.
- APRS I-Gate – 144.390, N4LMC-3. Greater Chattanooga, Lookout Mountain, TN, NW GA and NE AL areas.
